Shock absorption! Low noise! Improved operability!
*Max Torque: 1,000 ft-lbs
*Twin Dog Hammer Mechanism enables efficient hammering
*Gel-type elastomer-filled grip absorbs vibrations
*A filter built into the exhaust port reduces exhaust noises.
*Newly designed adjustment lever.
*3-step torque setting.
*Protector prevents the aluminum body from being scratched when placed.
*Made in Japan
Shock absorption! Low noise! Improved operability!
*Max Torque: 1,000 ft-lbs
*Twin Dog Hammer Mechanism enables efficient hammering
*Gel-type elastomer-filled grip absorbs vibrations
*A filter built into the exhaust port reduces exhaust noises.
*Newly designed adjustment lever.
*3-step torque setting.
*Protector prevents the aluminum body from being scratched when placed.
*Made in Japan
| Code | Model No. | Drive(inch) | Bolt capacity(inch) | Max Torque(ft-lbs) | Free Speed(rpm) | Air Consumption(CFM) | Operation air pressure(PSI) | Air hose inner O/D (inch) | Overall Length(inch) | Net Weight(lb) |
|---|---|---|---|---|---|---|---|---|---|---|
| 370196 | VSP-1148 |
1/2 | 3/4 | 1000 | 6600 | 1 | 90 | 3/8 | 7.8 | 5.5 |
Sound Level(dB)
104
Vibration Level(m/s²)
11.6
Exhaust
Front exhaust
Precautions
*To use the air tool safely, be sure to read attentively the instruction manual, understand fully the contents before use, and use in a right way.
*Wear protective goggles.
*Wear earplugs.
*Use the product with the proper air pressure.
*Any modification on the product is prohibited.
